ATEX approved to ATEX II 3G Ex nA IIC T4, two axes accelerometers now available, ranges +/-3g to +/-50g, DC upto 550Hz

Click here for data sheet:

ATEX SB2I

Model 4421 single axis accelerometer with less than 7µVRootHz noise, high temperature and long term stability. Available in ranges from +/-2g up to +/-200g. Fully signal conditioned, operating from unregulated 8-30VDC with either single ended or differential +/-2VDC output. 7000g shock survival.

Click here for the data sheet:

4421_4425

Model 5421 and 5721 two or three axes accelerometer with less than 17µVRootHz noise, high temperature and long term stability. Ranges from +/-2g up to +/-200g. Fully signal conditioned, operating from unregulated 8-30VDC with either single ended or differential +/-2VDC output. 7000g shock survival. The small cased model 5421 houses electronics in modules within the cable, model 5721 has a larger case housing all the electronics.

Click here for the data sheets:

5721.



5421

NEW OS115/315 single, dual and tri-axial accelerometers designed for offshore use, fully submersible to 10m, in ranges +/-2g to +/- 400g with very LOW NOISE

Click here for the data sheet:

OS 115/315

New IP67 and Stainless Steel housed dual and tri-axial accelerometer with less than 17µVRootHz noise. Ranges from +/-2g to +/-200g, fully signal conditioned and temperature compensated, withstands 7000g shock.

Click here for the data sheet:

5521

NEW from ASC, six axes IMU, 3 axes with linear sensors and 3 axis with gyros (rate sensors). Ranges from +/1g up to +/-500g and +/-100°/second up to 1500°/second.

Click here for the  data sheet

IMU

IMU Crash

New from ASC, DC referenced capacitive accelerometers with 4-20mA output, ranges from +/-1g to +/-200, single, dual and tri-axial versions available

Click here for the preliminary data sheet:

CS Series

PIEZO-RESISTIVE AUTOMOTIVE TEST AND CRASH TEST

NEW 3 AXES CRASH SENSOR Model 76C1 ranges available are +/-500g, +/-1000g and +/-2000g, mV output, small size and weight, DC response, high shock resistance, sensor TEDS/Dallas ID models available. Amplified version now available.

Click here for the data sheet

76

Single axis crash test sensor, Model 62C1, ranges available are +/-500g, +/-1000g and +/-2000g, mV output, small size and weight, DC response, high shock resistance, TEDS/Dallas ID models available.

Click here for the data sheet

62

New Tactical Grade Quartz Accelerometers, model AI-Q-710, click here for the data sheet:

AI-Q-710

Environmental Equipments.

Click here for the short form catalogue

EE Shortform

Please call or e-mail to obtain specific data sheets.

Model KAA low cost accelerometers in single, dual and tri-axial format, ranges from +/-2g to +/-200g, DC response, rugged hard anodised housing, quick delivery.

Click for the data sheets:

KAA 1 Axis



KAA 3 Axes
